RADIK CLEAN
Steel panel radiator for rooms with high demands on hygiene and cleanness with side connection
Steel panel radiator for rooms with high demands on hygiene and cleanness with side connection RADIK CLEAN is a steel panel radiator in the KLASIK version which allows a left or right side connection to the heating system. It is designed for pressurised or gravity-fed heating systems. It has been modified for installation and operation in rooms with higher demands on hygiene and cleanness. All types are supplied without convector fins, top grills and side panels. There are two upper and two lower hangers welded at the back side of the radiator. Radiators in length 1800 mm and more have six hangers. An air vent and blanking plugs are delivered as standard. We recommend using the drill-in brackets (type 18/120 – see the KORAMONT catalogue) which enable to mount the radiator in a distance of up to 65 mm from the wall. Notice: If the requested distance between the radiator and the wall should be 65 ÷ 80 mm, the same type of brackets can be used on condition that the lower hangers are fixed with brackets (not with supporting pieces only). In such a case the additional brackets must be ordered extra. Note: The RADIK CLEAN type 10 and RADIK KLASIK type 10 radiators are identical.
length from 400 to 2000 mm
height from 300 to 900 mm
heat output from 165 to 3364 W
left or right side connection
RADIK CLEAN we offer these in 154 alternatives
Filter by parameters
Selection of dimensions
Enter required dimensions.
Heat output (For professionals)
The heat output of the radiator should cover the specified heat losses of the heated room, which are calculated by the designer. t1 – temperature of input water entering the radiator t2 – temperature of output water exiting the radiator ti – relative air temperature (design temperature of air in the room) (Temperatures t1 and t2 are based on the design documentation of the heating system or the selected heat source)
Select colour
The basic colour is RAL 9016 white, other colours are subject to a surcharge.
It is possible to deviate the colour in the colour chart compared to the colour of the heating element.
Leave white
Free of charge
KORADO colour card
30 %
RAL colour card
40 %
Select alternative
|
Select all
|
Dimensions (H × L × D)
mm
|
Heat output
Tepelný výkon radiátoru má pokrýt stanovené tepelné ztráty vytápěné místnosti, které jsou vypočteny projektantem.
watt
|
Type
|
Color
|
Code for ordering
When ordering a coloured version please specify the colour code in the remark. The colour code is not a part of the article code.
|
|---|---|---|---|---|---|
|
Your selection
|
Dimensions (H × L × D)
(mm)
300 × 500 × 47
|
Heat output
(watt)
165
|
Type
|
Color
|
Code for ordering
10030050-50-0010
|
|
Your selection
|
Dimensions (H × L × D)
(mm)
300 × 600 × 47
|
Heat output
(watt)
198
|
Type
|
Color
|
Code for ordering
10030060-50-0010
|
|
Your selection
|
Dimensions (H × L × D)
(mm)
400 × 500 × 47
|
Heat output
(watt)
212
|
Type
|
Color
|
Code for ordering
10040050-50-0010
|
|
Your selection
|
Dimensions (H × L × D)
(mm)
400 × 600 × 47
|
Heat output
(watt)
254
|
Type
|
Color
|
Code for ordering
10040060-50-0010
|
|
Your selection
|
Dimensions (H × L × D)
(mm)
500 × 400 × 47
|
Heat output
(watt)
206
|
Type
|
Color
|
Code for ordering
10050040-50-0010
|
|
Your selection
|
Dimensions (H × L × D)
(mm)
500 × 500 × 47
|
Heat output
(watt)
257
|
Type
|
Color
|
Code for ordering
10050050-50-0010
|
|
Your selection
|
Dimensions (H × L × D)
(mm)
500 × 600 × 47
|
Heat output
(watt)
308
|
Type
|
Color
|
Code for ordering
10050060-50-0010
|
|
Your selection
|
Dimensions (H × L × D)
(mm)
500 × 700 × 47
|
Heat output
(watt)
360
|
Type
|
Color
|
Code for ordering
10050070-50-0010
|
|
Your selection
|
Dimensions (H × L × D)
(mm)
500 × 800 × 47
|
Heat output
(watt)
411
|
Type
|
Color
|
Code for ordering
10050080-50-0010
|
|
Your selection
|
Dimensions (H × L × D)
(mm)
500 × 900 × 47
|
Heat output
(watt)
463
|
Type
|
Color
|
Code for ordering
10050090-50-0010
|
Accessories
| Title | Description | Code | ||
|---|---|---|---|---|
|
Designed to be used for all types of the following models of panel radiators RADIK. Length 600 mm.
|
Z-D030
|
||
|
Designed to be used for all types of the following models of panel radiators RADIK. Length 900 mm.
|
Z-D031
|
||
|
Designed to be used for all types of the following models of panel radiators RADIK. Length 1200 mm.
|
Z-D032
|
||
|
Intended for cleaning all radiators KORADO.
|
Z-D029
|
Download or save your selection
Now save your chosen variant to you so that you can pass it on to the seller and thus speed up your purchase.
You will find the list of sellers in the next step.
Heat output and technical information
Technical Data
| H: Height (mm) | 300, 400, 500, 600, 700, 900 |
| L: Length (mm) | 400, 500, 600, 700, 800, 900, 1000, 1100, 1200, 1400, 1600, 1800, 2000 |
| Depth (mm) | |
| Type 10 | 47 mm |
| Type 20 | 66 mm |
| Type 30 | 155 mm |
| Highest allowed working temperature (°C) | 110 °C |
| Highest allowed working pressure | 10 bar |
| Connecting thread | G 1/2" inside |
| Connecting pitch | h = H – 54 mm |
Heat output
| Q [W] | Height [mm] | |||||
|---|---|---|---|---|---|---|
| Length (mm) | 300 | 400 | 500 | 600 | 700 | 900 |
| 400 | 206 | 242 | 278 | 350 | ||
| 500 | 165 | 212 | 257 | 302 | 347 | 438 |
| 600 | 198 | 254 | 308 | 362 | 416 | 525 |
| 700 | 360 | 423 | 486 | 613 | ||
| 800 | 411 | 483 | 555 | 700 | ||
| 900 | 463 | 544 | 625 | 788 | ||
| 1000 | 514 | 604 | 694 | 875 | ||
| 1100 | 565 | 664 | 763 | 963 | ||
| 1200 | 617 | 725 | 833 | 1050 | ||
| 1400 | 720 | 846 | 972 | 1225 | ||
| 1600 | 822 | 966 | 1110 | 1400 | ||
| 1800 | 925 | 1087 | 1249 | |||
| 2000 | 1028 | 1208 | 1388 | |||
| Q [W] | Height [mm] | |||
|---|---|---|---|---|
| Length (mm) | 500 | 600 | 700 | 900 |
| 400 | 359 | 417 | 474 | 585 |
| 500 | 449 | 522 | 593 | 732 |
| 600 | 538 | 626 | 712 | 878 |
| 700 | 628 | 730 | 830 | 1024 |
| 800 | 718 | 834 | 949 | 1170 |
| 900 | 807 | 939 | 1067 | 1317 |
| 1000 | 897 | 1043 | 1186 | 1463 |
| 1100 | 987 | 1147 | 1305 | 1609 |
| 1200 | 1076 | 1252 | 1423 | 1756 |
| 1400 | 1256 | 1460 | 1660 | 2048 |
| 1600 | 1435 | 1669 | 1898 | 2341 |
| 1800 | 1615 | 1877 | 2135 | |
| 2000 | 1794 | 2086 | 2372 | |
| Q [W] | Height [mm] | |||
|---|---|---|---|---|
| Length (mm) | 500 | 600 | 700 | 900 |
| 400 | 512 | 593 | 673 | 834 |
| 500 | 640 | 741 | 841 | 1042 |
| 600 | 767 | 889 | 1009 | 1250 |
| 700 | 895 | 1037 | 1177 | 1459 |
| 800 | 1023 | 1186 | 1346 | 1667 |
| 900 | 1151 | 1334 | 1514 | 1876 |
| 1000 | 1279 | 1482 | 1682 | 2084 |
| 1100 | 1407 | 1630 | 1850 | 2292 |
| 1200 | 1535 | 1778 | 2018 | 2501 |
| 1400 | 1791 | 2075 | 2355 | 2918 |
| 1600 | 2046 | 2371 | 2691 | 3334 |
| 1800 | 2302 | 2668 | 3028 | |
| 2000 | 2558 | 2964 | 3364 | |
Overview of Types
Type 10
Type 20
Type 30
Types of Connection
Side - one side
Side - two sides diagonal
Side - two sides direct
